TRIPLE RING BURNER
The triple ring burner must be correctly positioned (see fig. 7.3); the burner rib must be
enter in their logement as shown by the arrow.
The burner must be correctly positioned so that it cannot rotate (fig. 7.4).
Then position the cap A and the ring B (fig. 7.4 - 7.5).
