New World DFT91 - Removing the Oven Door

24
C
Fig. 7.13 Fig. 7.14
B
A
Fig. 7.11
Fig. 7.10
Fig. 7.12
REMOVING THE OVEN DOOR
The oven door can easily be removed as
follows:
– Open the door to the full extent (fig.
7.10).
– Open the lever A completely on the
left and right hinges (fig. 7.11).
– Hold the door as shown in fig. 7.13.
– Gently close the door (fig. 7.12) until
left and right hinge levers A are
hooked to part B of the door (fig.
7.11).
– Withdraw the hinge hooks from their
location following arrow C (fig. 7.14).
– Rest the door on a soft surface.
