Overview
No. Part Function Description
1 USB
For connecting USB devices such as mouse, keyboard and
USB ash memory. (FAT32).
2 USB/OTG
For connecting USB devices such as mouse, keyboard and
USB ash memory. (FAT32).
3 Micro SD card slot Support 1 GB/ 2 GB/ 4 GB/ 8 GB/ 16 GB/ 32 GB.
4 DC/5V For connecting AC adapter or power cable.
5 CVBS For connecting external speakers.
6 LAN For connecting local area network.
7 HDMI For connecting IFPD.
8 Optical (SPDIF) For connecting external speakers.
9 Indicator
Blue: Working state.
Red: Stand by state.
