Newmac NS220E - Wall and Ceiling Clearances by Model; Clearances for NC100 E Model; Clearances for NCM120 E Model

3
CLEARANCE TO COMBUSTIBLES, WALLS AND CEILING – NC100E Newmac Classic I EPA
Chimney Connector Type, genre de raccord de cheminée
Single Wall
paroi simple
Approved for clearance of 9” or less
Approuvé pour espacement de 9 po
(225mm) ou moins
A 18” (455mm) 10” (254mm)
B 36” (915mm) 36” (915mm)
C 48” (1220mm) 48” (1220mm)
D Min. 21” (533mm) Min. 21” (525mm)
E 18” (455mm) 9” (225mm)
F 51” (1295mm) 51” (1295mm)
CLEARANCE TO COMBUSTIBLES, WALLS AND CEILING – NCM120E Newmac Classic II EPA
Chimney Connector Type, genre de raccord de cheminée
Single Wall
paroi simple
Approved for clearance of 9” or less
Approuvé pour espacement de 9 po
(225mm) ou moins
A 10” (254mm) 10” (254mm)
B 14” (355mm) 8” (203mm)
C 12” (305mm) -
D 23” (785mm) 21” (482mm)
E 18” (455mm) 10” (254mm)
F 25” (635mm) -
G 36” (915mm) 36” (915mm)
H 48” (1220mm) 48” (1220mm)
K 51” (1295mm) 51” (1295mm)
