REPLACEMENT PARTS
List Part Numbers – Newmac Status EPA
Model NS220E Wood Heater
KEY NO.
PART NO. DESCRIPTION
1 2140050 Draft Control Knob
2 2210322 High/Low Label
3 2160006 Cotter Pin 1/16 x ¾”
4 2220005 Compression Spring
5 3090468 Thermostat Stop
6 3090459 Thermostat Standoff
7 3090393 BI Metal Thermostat Spring
8 3070013 Draft Door Chain
9 4060296 Primary Air Inlet
10 2150003 1/4” Flat washer
11 4060434 Smoke Pipe Baffle Assly
12 4060284 Cast Pipe Connector
13 4110600 Louvre Panel Painted
14 4060295 Burn Rate Dial
16 4060430 Rear Brick Rack Assly
17 4110574 Main Body Assly Painted
18 2030025 Split Brick Pumice 1 ¼ x 4 ½ x 9 (19 pieces)
19 4110570 Thermostat Controls Cover Painted
20 4160306 Firedoor C/W Rope Gasket Glued
21 4110539 Door Handle
22 2160011 Door Pins (7/32 x 3.25”)
23 3090450
Front Liner, Top
24 4060429 Primary Air Outlet
25 4110575 Base Panel Assly, Painted
26
3120163
3120160
Set Sold As
5200011
Brick Spacer
Bottom Brick Rack
27
4060425
4060426
Set Sold As
5200012
Right Top Brick Rack
Left Top Brick Rack
28 4110531 Door Catch Painted
29 3040244 Base Retainers (In Parts Bag 4100157)
30 2080049 Door Gasket 42” Rope
31 4100157 Parts Bag
32 2210243 Instruction Manual
33 4050215
**Timer Assembly
34 4110561 Wooden Handles, Stained Brown (In Parts Bag 4100157)
35 4060428 Super wool retainer
36 3070035 Super wool 607
37 4110571 Secondary Air Panel
38 4160307 Glass Door
39 2080103 Gasket
40 2080102 Ceramic Glass
41 3160451 Glass retainers (4 pieces)
**NOTE: Some parts available as complete assemblies only
