21
FLOOR BRACKET INSTALLATION – NC100E Classic I EPA, NCM120E CLASSIC II EPA
1. After heater is in position, set brackets in position as shown.
2. Drill 1/8” diameter holes in heater casing and floor for screws.
3. Insert floor wood screws, provided, (#10x1-1/2”) through bracket into floor.
4. Insert sheet metal screws, provided, (#10 x ¾” sheet metal) through bracket into casing, and secure.
Part Number Part Number required
4110562 Floor bracket 2
4100148 Screws bag 1
TO ORDER REPAIR PARTS
This manual will help you to obtain efficient, dependable service from the heater, and enable you to order repair parts
correctly. Keep in a safe place for future reference.
The use of the specified components is important. Do not use other than the specified components.
When ordering, always give the full model number on the identification plate attached to the back of the heater with the
following information:
1. The Part Number (not key number)
2. The Part Description
3. The Model Number of the appliance
4. Number of Parts Required
WARRANTY PROCESSING
The following is required to process warranty claims:
1. Owner’s name and address
2. Installer’s name, address, and phone number
3. Serial Number
4. Model Number
5. Installation Date
Newmac must issue a “Returned Goods Number” prior to acceptance of returned goods.
Refer to your “Newmac Wood-stove Limited Warranty” for terms and conditions.
