INSTALLATIEHANDLEIDING – P19 VERSION 0129NM02INT01 INSTRUCTION MANUAL – P19 | P19 0520NM19INT03
EN
NL
DEFR NO SE DK
Wall mounting
Installation materials
& power setting
Installation &
conguration of
accessories
Required tools & additional
materials (not provided)
- 4 x 6.3mm x 70mm Self Tapping pan
head Torx screws (DIN 7981C) stainless
steel (A4);
- 4 x plugs & rubber washers;
- 4 x Stainless steel (A4) washers;
- Drill and bit;
- Torx screwdrivers (T20);
- Voltage tester;
- Tape measure;
- Spirit level
- Power cable;
- Cable mount clips;
- RCD & MCB;
- For local conguration, a laptop with
RJ45 connectors and UTP cable
- Power cable 5 x Ø 2,5mm;
- Cable mount clips;
- UTP cable (CAT5 or CAT6);
- RJ12 UTP cable crimp tool;
- RJ12 connectors;
- Shunt 3 options:
> ABB S2C-A2 in combination with
S200 MCB or DS200 RCD
> Schneider IMX A9A26946 in
combination with ACTI9 RCD or MCB
> Legrand DX3 shunt trip (406278) in
combination with DX3 RCD or MCB
Package contents charge point
- Charge point;
- Rubber grommets (various sizes);
- 1 x M4 x 16 mm bolt (Torx);
- 6 x M4 x 12 mm bolts (Torx)
- 2 x Power cable clamps;
- 2 x UTP data cable inlet with rubber
seal
- Current Tranformer (only for 7,4 kW
model) for Load Shedding functionality;
- Load Shedding module (only for 11 kW
model) for Load Shedding functionality
3. PRODUCT OVERVIEW
3.1 MOUNTING, PACKAGE CONTENTS AND REQUIRED TOOLS
