3.2 TECHNICAL SPECIFICATIONS
3. PRODUCT OVERVIEW
CONTINUED ON NEXT PAGE
Serial number format Home Basic 7,4 kW
Serial number format Home Basic 11 kW
Maximum charge capacity
Standard congured charge capacity
Electric safety category
Connector type
Dimensions (H x W x D)
Weight
Standard colours
IEC-62262 IK code (robustness)
IEC-60529 IP code (protection class)
Certicates
User interface
Identication & start charging
Conguration
052 _ _ _ _ _
062 _ _ _ _ _
Home Basic 7,4 kW: single phase 32A*
Home Basic 11 kW: triple phase 16A*
Home Basic 3,7 kW: single phase 16A**
Home Basic 11 kW: triple phase 16A**
Class 1
Type 2S - socket with shutter
503.5 x 200 x 137 mm
± 4.0 kg
Rear side RAL 7031 (grey)
Front side RAL 9010 (white)
IK10
IP54 (for indoor and outdoor use)
IEC-61851-1
IEC-61851-22
EV-Ready & ZE-Ready
IEC-62262 -> IK10
IEC-60529 -> IP54
LED
No authorization (immediate recharging)
Local conguration using the conguration software via
standard UTP RJ45 on Windows (minimal Windows 10)
or Mac (minimal OS 10.14)
