The powercable connection on the terminal block of
the chargepoint should match the L1, L2 and L3 in the
chargepoint. For a 1 phase installed chargepoint the L1
measurement head should match the conduction which
is connected to the L1 of the terminal block.
Warning: Keep module switched o during installation
Step 1: Feed the UTP cable(s) through the rubber stop(s)
on the data cable inlet;
Step 2: Clamp a RJ12 connector straight to the cable
and then connect it to the P1 port, as indicated in the
’3.4.2 Overview Installing Accessories’ section;
Step 3: Don’t plug the power adapter in the power outlet
yet;
Step 4: Connect the power adapter to the Load
Shedding module. One of the two power adapter wires
has a broken white stripe. This wire is the power adapter
GND and should therefore be connected to the GND pin
(right) on the module. The other wire is the +5 Volts and
should be connected to the +5V pin (left) on the module.
The middle pin is not used;
Step 5: Connect the CT(‘s) to the Load Shedding
module;
Step 6: Install the Load Shedding module on the DIN
Rail in the fuse box;
Step 7: Apply the CT(‘s) to the grid connection(s). Make
sure to apply the CT(s) so that the total power usage of a
phase is measured;
Step 8: Plug the power adapter into a power outlet. The
PWR LED must light up;
Step 9: The CS LED will (after a few seconds) indicate a
measured current after the power is on;
Step 10: Prepare the cable between chargepoint and
Load Shedding module. The maximum length of the
cable between charge point and Load Shedding module
is 20 meters.
Step 11: Plug in the RJ12 cable to the Load Shedding
module
If both ends of the cable are properly connected to
the charge point & Load Shedding module and powered,
the P1 LED will indicate whether the connection is
correct.
5.6 LOCAL CONFIGURATION (UTP)
Make sure both the charge point and laptop are
powered on for at least 5 minutes.
Continue to Chapter 6 and follow instructions for local
conguration.
5.7 FINISHING UP (CLOSE ENCLOSURE)
Step 1: Check and make sure that the rubber seal
around the casing is properly in place on the edge;
Step 2: Place the cover on the charge point;
Step 3: Hand-tighten the four M4 x 12 mm bolts
provided around the socket so that the cover closes on
the rubber seal but the rubber seal does not deform;
Step 4: Hand-tighten the other two M4 x 12 mm bolts
provided in the bottom of the cover;
Step 5: Turn the socket lid clockwise in the cover and
hand-tighten the M4 x 16 mm bolt provided;
Step 6: Switch on power to the charge point;
Step 7: Wait until charge point is fully started up (+/-10
minutes, LED should be o)
