11
8.3 How To Control The Motor
8.3.1 On/O Speed Control
Rotate handle clockwise to obtain any of the 5 forward speeds. Rotate
handle counter clockwise for any of the 3 reverse speeds. To stop the
8.2 Battery Connection Method (24 Volt only)
8.2.1 Connection With Two Batteries in Series (24V DC)
The red wire should connect to positive; the black wire should connect
to negative. (It is recommended to install circuit breaker in line with pos-
itive lead.)
Remember to always disconnect from the battery(s)
once the motor leaves water as a rotating propeller can cause personal
injury
to Select Gears
Extendable
