7 Battery Meter Reading
When the motor is connected to the battery, the battery meter will light
up to indicate the amount of power left in the battery. There are ten LED
lights on the top cover. When seven LED’s are out, the meter is indicat-
ing that the input voltage is less than 9.5V (normal voltage draw is 12V).
At this point it is advised to disconnect the motor from the battery to
prevent damage to the battery and recharge.
It is important to pay attention to the remaining power of the battery,
make sure to reserve enough battery power that you can travel back
with motor.
This battery voltage meter is only designed for 12V
deep cycle battery power supply system (24V for the 86lbs motor), not
for lithium battery system. You cannot trust the reading if the motor is
powered by the lithium battery.
Meter
