Nexo ID Series

TECHNICAL SPECIFICATIONS
IDS110 - IDS210 - Accessories Page 11 / 14
TECHNICAL SPECIFICATIONS
IDS110 – IDS210 WITH NEXO ELECTRONICS
Model
IDS110
IDS210
Frequency Range
43Hz  130Hz (+/- 3dB)
43Hz  130Hz (+/- 3dB)
Sensitivity (1W / 1m)
97dB SPL Nominal
103dB SPL Nominal
Operating voltage
45Vrms (180Vpeak)
45Vrms (180Vpeak)
Peak SPL Level (1m)
125dB Peak
131dB Peak
Crossover Frequency
85Hz / 120Hz
85Hz / 120Hz
Nominal Impedance


Recommended Amplification
400 to 650W
800 to 1300W
SPECIFICATIONS
Model
IDS110
IDS210
Components

2
Material
Finnish birch plywood
Finish
Black or White structured paint
Fittings
4x M6 Inserts
M20 flange (t version only)
Connector
Touring version: 2x NL4, 4 poles connectors
Instal version: 1x Cable gland with 2 cores cable
Weight
21 kg / 47 lb
37 kg / 82 lb
Dimensions
