EQUIPMENT
IDS110 - IDS210 - Accessories Page 5 / 14
Assembly on distance rod or speaker stand
Place distance rod on the connector plate (M20) of the Sub.
Place ID24 on the distance rod / monitor stand
IMPORTANT
Speaker stand must be rated for ID24 weight.
Speaker stand must always be installed on a horizontal surface.
Stand height and footprint must be defined to prevent assembly
from collapsing.
Ensure that audience is not allowed within a safety area which
radius is equal or higher than assembly height.
Test steadiness of the assembly by pushing in all directions.
WARNING:
Height H must not exceed 2 m (6.6 ft).
The M20 base plate located on IDS110t and IDS210t should be
used only with speakers like ID24 with the IDT-TVP accessory
attached
The distance rod M20 35mm is not supplied.
