ENGLISH
PAGE 24
MENU DESCRIPTION
Input Patch, MENU3.2
Each output (or group of outputs when a system uses more
than one output per cabinet – like the Alpha M3 or
CD12/CD18 subs) may be configured to receive either
LEFT, RIGHT or (LEFT+RIGHT) inputs. The Left and Right
mode sums the two inputs together, but attenuates the
level by 6dB to compensate.
It is thus possible to drive the main system from the LEFT
input while the sub is driven by the RIGHT input and fed to
the AUX of the mixing desk. However some precautions
must be taken while splitting the system between MAIN
and AUX outputs of the mixing desk. See the application
note at the end of this manual.
NX242 USER MANUAL LOAD2_22
DATE : 12/3/2004
