NEXO NX242 DIGITAL TDcontroller Service manual rev100606
P.2
2
R0005 R0006 R0007 R0008 R0009 R0010 R0011
R0012
8 Resistor metal film (SFR25), thru hole tol=1% 330 R
R2513 1 Resistor Medium Power 3W 33 K
R2532 R2534 2 Resistor Medium Power 3W 270 R
R1221 R1222 R1321 R1322 R1603 R1604 R1606
R1608 R1609 R1610 R1612 R1614 R1615 R1616
R1618 R1620 R1621 R1622 R1624 R1626 R1409
R1410 R1411 R1412 R1413 R1414
58 Resistor Metal film 1/4W tol 1%, case 1206 or 0805 1 K
R1706 R1806 R1906 R2006 4 Resistor Metal film 1/4W tol 1%, case 1206 or 0805 8.87 K
R1715 R1716 R1815 R1915 R2015 4 Resistor Metal film 1/4W tol 1%, case 1206 or 0805 12.4 K
R1212 R1312 R1714 R1814 R1914 R2014 6 Resistor Metal film, SMD, 1/4W, tol =1%, case 1206-0805 1.05 K
R1002 1 Resistor Metal film, SMD, 1/4W, tol =1%, case 1206-0805 1.2 K
R1211 R1311 R1713 R1813 R1913 R2013 6 Resistor Metal film, SMD, 1/4W, tol =1%, case 1206-0805 1.47 K
R1001 1 Resistor Metal film, SMD, 1/4W, tol =1%, case 1206-0805 1.8 K
R1210 R1310 R1712 R1812 R1912 R2012 6 Resistor Metal film, SMD, 1/4W, tol =1%, case 1206-0805 2.05 K
R2507 R2522 R2609 R2611 4 Resistor Metal film, SMD, 1/4W, tol =1%, case 1206-0805 2.74 K
R1209 R1309 R1711 R1811 R1911 R2011 6 Resistor Metal film, SMD, 1/4W, tol =1%, case 1206-0805 2.87 K
R2505 1 Resistor Metal film, SMD, 1/4W, tol =1%, case 1206-0805 3.3 K
R2509 R1627 R1628 R1629 R1630 5 Resistor Metal film, SMD, 1/4W, tol =1%, case 1206-0805 825 R
R2524 1 Resistor Metal film, SMD, 1/4W, tol =1%, case 1206-0805 3.92 K
0 Resistor Metal film, SMD, 1/4W, tol =1%, case 1206-0805 4.42 K
