NEXO NX242 DIGITAL TDcontroller Service manual rev100606
P.2
4
R2501 R2502 2
Resistor Metal film, SMD, 1/4W, tol =1%, case 1206-0805 560 K
R5301
1 Resistor Metal film, SMD, 1/4W, tol =1%, case 1206-0805
681 K
R1722 R1822 R1922 R2022 4
Resistor Metal film, SMD, 1/4W, tol =1%, case 1206-0805 750 K
R2525 R2526 2
Resistor Metal film, SMD, 1/4W, tol =1%, case 1206-0805 1 M
R2510 R2511 2
Resistor Metal film, SMD, 1/4W, tol =1%, case 1206-0805 220 R
R1419 R1420 R1421 R1422 R1423 R1424 R1425
R1426 R1601 R1602 R2512
11
Resistor Metal film, SMD, 1/4W, tol =1%, case 1206-0805 10 R
R1707 R1708 R1807 R1808 R1907 R1908 R2007
R2008
8
Resistor Metal film, SMD, 1/4W, tol =1%, case 1206-0805 15 R
R2514 1 Resistor Metal film, SMD, 1/4W, tol =1%, case 1206-0805
22.1 R
R5001 R5002 R2523 R0018 R0019 R0020 R0021
R0022 R0023 R0024 R0025
11
Resistor Metal film, SMD, 1/4W, tol =1%, case 1206 100 R
R1517 R1518 R1519 R1520 4
Resistor Metal film, SMD, 1/4W, tol =1%, case 1206-0805 150 R
R2520 1 Resistor Metal film, SMD, 1/4W, tol =1%, case 1206-0805
180 R
R2601 R2608 R2610 3
Resistor Metal film, SMD, 1/4W, tol =1%, case 1206-0805 243 R
R5503 R5504 R5505 R5506 R5507 R5508 R5509
R5510 R5511 R5512 R5513 R5514 R5515 R5516
R5517 R5518 R5519 R5520
18
Resistor Metal film, SMD, 1/4W, tol =1%, case 1206-0805 332 R
R1215 R1315 R1720 R1820 R1920 R2020 6
Resistor Metal film, SMD, 1/4W, tol =1%, case 1206-0805 365 R
R2602 1 Resistor Metal film, SMD, 1/4W, tol =1%, case 1206-0805
390 R
R1523 R1524 R5003 R5004 4
Resistor Metal film, SMD, 1/4W, tol =1%, case 1206-0805 470 R
R1214 R1314 R1719 R1819 R1919 R2019 6
Resistor Metal film, SMD, 1/4W, tol =1%, case 1206-0805 511 R
R1213 R1313 R1718 R1818 R1918 R2018 6
Resistor Metal film, SMD, 1/4W, tol =1%, case 1206-0805 715 R
