Nexo PS 8 - PS15 Passive & RS15 Omni with PS15 TDController

CONNECTION DIAGRAMS Page 23/82
5.7 PS15 Passive & RS15 Omni with PS15 TDController
AMPLIFIER 1
AMPLIFIER 2
MONO
STEREO
Speakon 4
Speakon 4
Speakon 4
Speakon 4
1 (+) / 1 (-) RS15
2 (+) / 2 (-) PS15
TO AMPLIFIERS
B ALANC E D IN P UT S
RIGHT
LEFT
-
6dB
-
12dB
0dB
OUT P UT
L
E V E L
B ALANC E D OUT P UT S
RIGHT LEFTSUB L+R
E A R TH
LI
F T
FROM AMPLIFIERS
+ 3-
+ 2 - + 1 -
S E N S E IN P UT
(from amp terminals)
CAUTION !
Sense must be connected for
speaker protection
SEE USER MANUAL
STEREO
IN
PS15 LEFT
PS15 RIGHT
RS15 OUT
PS15 LEFT
PS15 RIGHT
RS15
