TECHNICAL SPECIFICATIONS Page 59/82
9.2.2 Dimensions
316 mm
[12.44"]
515 mm
[20.28"]
277 mm
[10.91"]
30˚
45˚
435 mm
[17.12"]
688 mm
[27.09"]
528 mm
[20.79"]
