Page 44/82 PS SERIES HARDWARE SETUP PROCEDURE
Lock
or
Truss suspension
• Connect truss hook VNT-TCBRK to “U” bracket by inserting 8x45 quick release pin in dedicated
holes;
• Ensure truss hook is properly locked to “U” bracket;
• Lift and position assembly, lock hook on truss suspension point and secure with hook cable.
PS SERIES HORIZONTAL SUSPENSION PROCEDURE
Unlocking the “u” bracket safety locker
• Lift the metal plate located at the corner of the bracket and unfold the side bar
UNLOCKING „U“ BRACKET SAFETY LOCKER
