Nexo PS8 User Manual

PS8, PS8TD & LS400 : SPECIFICATIONS, CURVES & DIAGRAMS
___________________________________________________________________________________________________
P.31
SHIPPING & ORDERING
Packaging
PS8's are packaged as pairs with or without PS8TD in a single box.
Shipping weight & Volume
2 x PS8.U = 16 Kg (35.28 lb.) 0.109 cu m (3.85 cu feet).
2 x PS8.U + 1 x PS.8TD = 19.00 Kg (6.61 lb.) 0.109 cu m (3.85 cu feet).
LS.400 = 22 kg (48.5 lb.) 0.130 cu m (4.59 cu feet).
Accessories
A full selection of mounting Accessories is available, please contact your Nexo Agent for details.
As part of a policy of continual improvement, NEXO reserves the right to change specifications without notice.
[a] Response curves & data : Anechoïc Far Field for the PS8 + PS8TD. Half-Space Anechoïc radiation for the LS400 + PS8TD.
[b] Sensitivity & Peak SPL data : these will depend on spectral distribution and crest factor of program material. Measured with band limited Pink Noise. Nominal refers to
Voice Decade (300 Hz - 3 kHz), Wideband to the specified ±3dB range. Data are for speaker + processor + recommended amplifier combinations. Peak SPL is at
clipping of recommended amplifier.
[c] Directivity curves & data : obtained by computer treatment on off axis response curves.
Dimensions

Nexo PS8 Specifications

General

Nominal Impedance	8 Ohms
Power Handling	200 Watts RMS
Connectors	2 x NL4
Type	Passive
Woofer	8"
Tweeter	1"
Recommended Amplifiers	100 W - 400 W at 8 ohms
Components	1 x 8" woofer, 1 x 1" tweeter
