- Installation instructions for supplementary outriggers -
Via Mediterraneo, 6 - 42022 - Boretto - Reggio Emilia - Italy
Tel. +39 - 0522-96 30 08 - Fax +39 - 0522-96 30 39
info@maxiliftcrane.com
- 29 -
TABLE OF WEIGHTS W/O PACKING
When moving and lifting by means of bends, chains or other slings, always bear in mind the
recommendations and safety prescriptions required for loads lifting, and in particular:
1] always make sure that the weight of
the stabilizer handled is lower than
the loading capacity of the lifting
equipments you intend to use, using
the above table as a reference
2] keep the operating area free from
people and things
3] the stabilizers could be not
symmetrically balanced as far as
the distributions of their weights is
concerned, especially if you need to
rotate them in order to overturn
them. Their barycentre is extremely
variable, even for the same model,
but according to the different version
chosen, options installed, etc. Pay
extreme attention to rough
movements and impacts which
could come from them!
As far as possible, try and apply the
lifting equipments in order to balance
the weight.
Model kg
ML - E 95
0 EMO 125
1 EMO 185
1 EHO 210
2 EMO 240
2 EHO 260
Model kg
5 EXHA 910
6 EXHA 1210
6 EXPHA 1360
5 EXPHA 1010
7 EXPHA 1590
Model kg
ML - F 65
0 F 80
1 F 130
2 F 185
Model kg
1 EMA 245
1 EHA 280
2 EMA 345
2 EHA 385
3 EHA 435
4 EHA 510
5 EHA 680
5 ELHA 800
Pict. 31
8 EXPHA 1740
1400
