Shark SD110/SD120 | 21
Shark SD110/SD120 Specifications
General
• Piranha FX Measurements
o Overall Machine Dimensions: X: 19.5” Y: 20.5” Z: 18”
o Work Table Dimensions: 12” X 18”
o Maximum Cutter Travel: X: 12” Y: 13” Z: 3”
• Piranha XL Measurements
o Overall Machine Dimensions: X: 19.5” Y: 30.5” Z:24”
o Work Table Dimensions: 12” x 30”
o Maximum Cutter Travel X:12” Y:24” Z: 4”
• Bearings: 12 precision linear bearing guides (4 on each axis) that maximize rigidity
• High power hybrid 1.8 degree stepper motors rated at 269 oz/in
• USB interface with on controller memory storage
• 24V power supply to provide full power to the stepper motors
• Precision lead screws with anti-backlash on all axis
• Work table – T-Slotted Extruded Aluminum
Rates and Accuracy
• Resolution: ~+/- 0.001 inch;
• Reproduction accuracy depends on the precision of the setup and alignment – but is in
the same range or better.
• High Speed Positioning (jogging) Rate: 120 ipm
Computer Requirements
The current minimum system requirements for running VCarve:
• 2 GHz Pentium 4
• 60 Mb Disk Space
• 2 Gb RAM
• 1024x768 graphics display
• DVD ROM drive
• USB 2.0
• Operating system: Windows 7, Windows 8, Windows 10
VCarve will run faster with a better processor and more memory than listed in the minimum
system requirements.
Other operating systems, for example iOS (Apple) and Linux, are not currently supported.
The computer used to connect to the Controller Interface must have a USB 2.0 port. The
Controller Interface will not work with a computer connected with a USB 1.0 or 1.1 port, or a
USB hub that is not powered.
