LA12 & LA12C User’s Guide
16
negligible noise-floor level, making the LMS240i one of the processors with best technical
specifications in the market.
2.3 SPEAKER CABLE REQUIREMENTS
Speaker cables terminate at the speakers with an 8-conductor Neutrik NL-8 connector.
One cable reaches from the amplifiers rack to a single LA12 (LA12C). A short jumper cable
then connects an additional LA12 (LA12C) speaker in parallel to the first.
If you are using sub-woofers, it is usually ideal to have one cable each from the amp
rack to every subwoofer. Under heavy-use applications, jumpering sub-woofers in parallel
may reduce system performance capabilities.
The LA12 (LA12C) full-range speaker connections are labeled on the rear connector
panel. One Neutrik NL-8 connector is wired as follows:
