10
Camera Parts and Controls (cont.)
See below to identify the parts and controls of your Dash Cam
USB Cover
USB port located under the dust cover.
Light Sensor
When Screen Dimming is turned ON in the Setup Menu, the screen brightness
is automatically adjusted relative to the ambient light levels.
Reset Button
Press to force a hard restart of the Dash Cam.
8
9
10
Power Button
Press and hold for 2 seconds to turn the Dash Cam On/Off. Short press, acts as a
back button when in the Menus.
MicroSD Card Slot
Insert the MicroSD card here, taking care that the gold contacts are facing towards
the rear of the Dash Cam.
HD-Out/Rear Cam Input
Connection point for the Rear Cameras and TV Connection, see page 38.
Polarising Filter
Reduces the glare on the windscreen to help record clearer videos.
See page 16 for setup information.
11
12
13
14
11
9
8
12
13
14
10
HD-OUT
R-CAM
R E S E T
