DFS series User’s Manual REV 3.8 November 2016
16
If the % offset is between 5% - 10 % please contact your supplier to
arrange a recalibration of your gauge.
If the % offset is greater than 10% please contact your supplier to
arrange for load cell replacement.
*These values are given as an indicator only – the need for
calibration/repair may vary according to the individual characteristics of the
load cell.
6) SELECT OUTPUT Use this menu to select between USB or PS/2 (RS232)
Output. Select one of the two available options based on connection type. The
default mode of the output port is USB output if no selection is made.
OUTPUT MENU
1) USB OUPUT
2) PS/2 OUTPUT
Figure 9 Output Menu
7) ABOUT This page shows information relevant to your gauge (Firmware
revision, Model type, Gross maximum capacity, and Serial number).
ABOUT
FIRMWARE REV. : 3.0
MODEL: DFS
CAPACITY: 100 N
S/N: 05130001
Figure 10 About Menu
