12
Step 12: Attach (1) Top Plate to the top of each set of Top Support Brackets using (8) 6 x 12 FHMS.
Step 13: Attach the Screen Back Plate both of the Screen Supports using the (8) 3/8 – 16 x3/4” BHMS.
Tip: You can generally measure from the Top of the TV to the center of the VESA, this is the distance the
center of the Screen Back Plate will need to be from the Top Support Brackets.
