Below is a parts list describing all of the items included with the Model DL-50 Lift System. You may also wish to
refer to the dimensional diagram shown on “Supplemental Page A” (at the end of this document).
Before beginning assembly and installation, please make sure that you have all items included on the list. If any
parts are missing or damaged, please contact Nexus 21. Our contact information is shown at the top of this
page.
Parts List
Screen Supports (2)
Column Clamp Extension (2)
Screen Back Plate (1)
Lift Columns (2)
Top Support Brackets (4)
Column Clamp Base (2)
Base Mounts (2)
Top Plate (2)
Vertical Mounting Bars (2)
