NEXUS 7 GUIDEBOOK APPENDIX 70
Nexus 7 hardware
NOTE: SIM card tray is available only for Nexus 7 with mobile
data, and microphone is lower on Wi-Fi-only model.
Touch screen
Front-facing
camera
3.5mm
headset jack
Micro
USB port
Speaker
Microphone
Microphone
NFC area
4-pin
connector
SIM card
tray
Volume key
Power/lock
key
SIDE SIDE
BACK
FRONT
BOTTOM
