Page 10 For technical questions, please call 1-888-866-5797. Item 56645
PLEASE READ THE FOLLOWING CAREFULLY
THE MANUFACTURER AND/OR DISTRIBUTOR HAS PROVIDED THE PARTS LIST AND ASSEMBLY DIAGRAM
IN THIS DOCUMENT AS A REFERENCE TOOL ONLY. NEITHER THE MANUFACTURER OR DISTRIBUTOR
MAKES ANY REPRESENTATION OR WARRANTY OF ANY KIND TO THE BUYER THAT HE OR SHE IS
QUALIFIED TO MAKE ANY REPAIRS TO THE PRODUCT, OR THAT HE OR SHE IS QUALIFIED TO REPLACE
ANY PARTS OF THE PRODUCT. IN FACT, THE MANUFACTURER AND/OR DISTRIBUTOR EXPRESSLY
STATES THAT ALL REPAIRS AND PARTS REPLACEMENTS SHOULD BE UNDERTAKEN BY CERTIFIED AND
LICENSED TECHNICIANS, AND NOT BY THE BUYER. THE BUYER ASSUMES ALL RISK AND LIABILITY
ARISING OUT OF HIS OR HER REPAIRS TO THE ORIGINAL PRODUCT OR REPLACEMENT PARTS
THERETO, OR ARISING OUT OF HIS OR HER INSTALLATION OF REPLACEMENT PARTS THERETO.
Parts List and Diagram
Parts List
Part Description Qty
1 Nozzle Cap 1
2 Nozzle O-Ring 1
3 Joint 1
4 Wand O-Ring 2
5 Split Sleeve 2
6 Wand Nut 2
7 Wand 1
8 Trigger 1
8-1 Trigger Lock 1
8-2 Trigger Lever 1
8-3 Trigger Nut 1
8-4 Trigger Spring 1
8-5 Valve Core 1
8-6
Valve Core O-Ring 1
8-7 Trigger Sealing Pad 1
8-8 Trigger Pin 1
8-9 Trigger Body 1
8-10 Trigger Sealing Ring 1
8-11 Wand Handle Filter 1
8-12 Wand Handle 1
9 Hose Nut 1
10 Hose 1
11 Hose Locking Ring 1
12 Tank Lid 1
13 Air Intake Plug 1
14 Tank Gasket 1
15 Tank Filter 1
16 Tank 1
17 Back Pad 1
19 Screw, M6 x 12 2
20 Screw, M6 x 18 2
21 Nut, M6 2
22 Air Chamber O-Ring 1
Part Description Qty
23 Air Chamber 1
24 Pump O-Ring Ø29 1
25 Pump O-Ring Ø49 1
26 Screw ST4×8 2
27 Flat Gasket 2
28 Pump Valve Gasket 2
29 Pump Cylinder 1
30 Piston Spring 1
31 Piston Bowl 1
32 Piston 1
33 Connecting Rod Clamp 1
34 Connecting Rod Calibre 1
35 Operation Arm 1
36
Inner hex Screw, M8 x 25 2
37 Nut, M5 2
38 Pump Locking Ring 1
39 Screw, M5 1
40 Piston Cover 1
41 Screw, M5 x 25 1
42 Screw, ST3 x 10 2
43 Pump Handle Cover 1
44 Pump Handle 1
45 Nut, M5 1
46 Turning Rod 1
47 Flat Gasket 2
48 Turning Rod Sleeve 2
49 Split Pin 1
50 Screw, M5 x 25 1
51 Shoulder Strap 1
52 Cone Nozzle 1
53 Fan Nozzle 1
54 Double Cone Nozzle 1
55 Adjustable Jet Nozzle 1
To Next Page
