Control
VVM 240
38
Miscellaneous
Menu 8.2.0 Operating mode
Settings regarding auto mode can be made in the sub-
menus to this menu.
Operating mode.
8.2.0
Menu 8.2.2 Wintertemp
The average outdoor temperature when the circulation
pump and immersion heater are blocked is selected
here. The value is adjustable between 0 and 30 °C.
15°C
Wintertemp
8.2.2
Menu 8.2.3 Return
Pressing the enter button returns you to menu 8.2.0
Return
8.2.3
Menu 8.2.1 Summertemp.
The average outdoor temperature when the circulation
pump and immersion heater are blocked is selected
here. The value is adjustable between 0 and 30 °C.
20°C
Summertemp.
8.2.1
Menu 8.3.0 Current limiter
Settings and readings regarding the load monitor are
set on the submenus to this menu.
Current limiter
8.3.0
Menu 8.3.2 Max. elec add on
The setting selected on the load monitor card (2) knob
(101) is shown here.
9.0 kW
Max. elec add on
8.3.2
Menu 8.3.7 Return
Pressing the enter button returns you to menu 8.3.0.
Return
8.3.7
Menu 8.4 Return
Pressing the enter button returns you to menu 8.0.
Return
8.4
Menu 8.3.1 Fuse size
The setting selected on the load monitor card (2) is
shown here knob (100).
16 A
Fuse size
8.3.1
Menu 8.3.3 Current phase 1
Shows the measured current from the current sensor,
phase 1. When the value falls below 2.0 A, low is
shown on the display.
3.5 A
Current Phase 1
8.3.3
Menu 8.3.4 Current phase 2
Shows the measured current from the current sensor,
phase 2. When the value falls below 2.0 A, low is
shown on the display.
3.3 A
Current Phase 2
8.3.1
Menu 8.3.5 Current Phase 3
Shows the measured current from the current sen-
sor, phase 3 When the value falls below 2.0 A, low
is shown on the display.
3.3 A
Current Phase 3
8.3.5
Menu 8.3.6 Factor
The transfer value must be defined depending on the
current transformers used for the load monitor card.
This is done in this menu. The value is adjustable
between 100 and 900 in increments of 10. The setting
300 applies for the supplied current transformers.
300
Factor
8.3.6
U
U
U
U
U
U
U
U
U
U
