Accessories

VVM 240

50

LEK

10

15

20

25

30

°C

Room thermostat RT 10

Modular cable

FIGHTER 2010

LEK

LEK

Lower cabinet

height: 375 mm

Part no 089 196

Raising foot

height: 125 mm

Part no 089 195

Part no 418 366

LEK

FIGHTER 2010-6

FIGHTER 2010-8

LEK

Modular cable, 15 m

with connector

Part no 418,469
