Technical specifications
51
VVM 240
Enclosed kit
LEK
NIBE AB
Utetemperatur givare
Outdoor temperature sensor
Aussentemperatur fühler
Artikel 018764
Outside sensor
Current sensor
Feet
LEK
LEK
LEK
Volume, expansion vessel 10 litres
Design pressure, water heater 1,0 MPa (10 (bar)
Required ceiling height 1 835 mm
Depth 610 mm
Volume total 240 litres
Volume water heater 170 litres
Supply voltage 400 V~ 3-phase + N
Rated output circulation pumps 45 / 75 / 110 W (adjustable)
Design pressure in double jacket volume 0,25 MPa (2.5 (bar)
Height (excl. foot: 15 40 mm(mm) 1 710 mm
Width 600 mm
Weight 150 kg
Volume double jacket 70 litres
Output immersion heater 13,5 kW (delivery output 9.0 kW)
Enclosure class IP21
Max pressure in double jacket volume 0,25 MPa (2.5 (bar)
Initial pressure expansion tank 0,5 (bar) (5 mvp)
Adjustable max boiler temperature 55 – 80 °C
IP 21
Design pressure, water heater 0,9 MPa (9 (bar)
LEK
Modular cable, 15 m
