Here you set the start and stop temperature of the hot water
for the different demand modes in menu 2.2 as well as the
stop temperature for periodic increase (menu 2.4).
MENU 7.1.2 - CIRCULATION PUMPS
This menu contains sub-menus where you can make ad-
vanced circulation pump settings.
MENU 7.1.2.1 - OP. MODE HM PUMP GP1
Operating mode
Alternative: Auto, continuous
Auto: The heating medium pump runs according to the
current operating mode for VVM S320.
Continuous: Continuous operation.
MENU 7.1.2.2 - PP SP. HEATING MEDIUM GP1
Heating
Auto
Setting range: on/off
Manual speed
Setting range: 1 - 100 %
Minimum permitted speed
Setting range: 1 - 50 %
Maximum permitted speed
Setting range: 50 - 100 %
Speed in wait mode
Setting range: 1 - 100 %
Hot water
Auto
Setting range: on/off
Manual speed
Setting range: 1 - 100 %
Cooling
Speed during active cooling
Setting range: 1 - 100 %
Auto
Alternative: on/off
Manual speed
Setting range: 1 - 100 %
Make settings here for the heating medium pump's speed
in the current operating mode, for example in heating or hot
water operation. Which operating modes can be changed
depends on which accessories are connected.
Heating
Auto: Here, you set whether the heating medium pump is
to be regulated automatically or manually.
Manual speed: If you have opted to control the heating me-
dium pump manually, you set the desired pump speed here.
Minimum permitted speed: Here, you can restrict the pump
speed to ensure that the heating medium pump is not al-
lowed to operate at a lower speed in auto mode than the set
value.
Maximum permitted speed: Here, you can restrict the pump
speed to ensure that the heating medium pump is not al-
lowed to operate at a higher speed than the set value.
Speed in wait mode: Here, you set the speed the heating
medium pump will have in standby mode. Standby mode
occurs when heating or cooling operation is permitted but
there is no need for either compressor operation or electric
additional heat.
Hot water
Auto: Here, you set whether the heating medium pump is
to be regulated automatically or manually in hot water mode.
Manual speed: If you have opted to control the heating me-
dium pumps manually, you set the desired pump speed here
in hot water mode.
Cooling
Speed during active cooling: Here, you set the desired pump
speed for active cooling.
Auto: Here, you set whether the heating medium pump is
to be regulated automatically or manually.
Manual speed: If you have opted to control the heating me-
dium pump manually, you set the desired pump speed here.
MENU 7.1.5 - ADD. HEAT
This menu contains sub-menus where you can make ad-
vanced additional heat settings.
MENU 7.1.5.1 - INT ELEC ADD HEAT
Max. connected el. power
Setting range: 7 / 9 kW
Max set electrical power
Setting range 3x400V: 0 – 9 kW
Setting range 1x230V: 0 – 7 kW
Max set electrical power (SG Ready)
Setting range 3x400V: 0 – 9 kW
Setting range 1x230V: 0 – 7 kW
Here you set the max electrical power for the internal electric
additional heat in VVM S320, during normal operation and
in overcapacity mode (SG Ready).
If the heat pump’s electric additional heating has been
switched from 7 kW to 9 kW, this is set in "Max. connected
el. power".
MENU 7.1.6 - HEATING
This menu contains sub-menus where you can make ad-
vanced settings for heating operation.
NIBE VVM S320Chapter 9 | Control – Menus52
