Nice Apollo 15501K - Actuator - Back

32
PARTS LIST
DESCRIPTION
PART NUMBER
QTY
ITEM
MOTOR & PINION GEARA2014
11
LIMIT TOWER & PLATEA2001
1
2
LIMIT BOLTA200523 PROXIMITY SWITCHA200424 LIMIT BLOCK - PLASTICA2003P2
5
BRASS BLOCK W/MAGNETA200216 BACK, HOUSINGA2012K17 LIMIT CAP & SEALA201028 STRAIN RELIEFA2029
1
9
SMART SENSOR (816 Only)A2072110 HARNESS - See Note11 1
1 1
2 2
A A B B
Company: NICE APOLLO
Description: Actuator Back Housing
7
8
11
9
1
10
2
Note:
These Items are sold as 1 unit also:
Back Housing Kit
Part # A2012
4
5
6
Note: 416 - 8' Cable (Part# A2028) 416X - 38' Cable (Part# A2037) 816 - 8' Cable (Part# A2058) 816X - 38' Cable (Part# A2041)
3
These Items also sold as one unit
Part# A2038
