4 - English
EN
––– Selecting the channel on the transmitter –––
On the FLOR series of transmitters, the association of the
transmitter key with the receiver channel can be modified:
• For key 1 of the transmitter, proceed as shown in fig. 4a:
cut the track that associates key 1 with channel 1 and con-
nect one of the other spots on the right with a drop of tin, to
obtain the association with channel 2, 3 or 4.
• For key 2 of the transmitter, proceed as shown in fig. 4b.
4a
4b
1
st
CHANNEL
2
nd
CHANNEL
1
st
CHANNEL
2
nd
CHANNEL
3
rd
CHANNEL
4
th
CHANNEL
2
nd
KEY
1
st
KEY
CUT
CUT
4
th
CHANNEL
3
NA NC
3
rd
CHANNEL
relay 2 relay 1
relay 2 relay 1
