LP21/LP22 Installation instructions en Sensors
The following parameters can be adjusted with the DIP switch:
DIP switch
Position
Value
Sense a
ON
0.01% (high)
Sense b
ON
Sense a
OFF
0,04%
Sense b
ON
Sense a
ON
0,16%
Sense b
OFF
Sense a
OFF
0.64% (low)
Sense b
OFF
Frequency
OFF
low
ON
high
Hold time
OFF
5 minutes
ON
Infinite
Output 2
OFF
Pulse signal
ON
Continuous signal
Edge 2
OFF
on entering
ON
on leaving
Inv. Out 1
OFF
Output inverted
ON
Output not inverted
Inv. Out 2
OFF
Output not inverted
ON
Output inverted
Tab.9: Settings via DIP switch (LP21)
