Nice MBar User Manual

Stop Indicates whether there is an error in the memorised data regarding the conguration of the alt input.
Bluebus Indicates whether there is an error in the memorised data regarding the conguration of the devices connected to
the bluebus input.
Positions Indicates whether there is an error in the memorised data regarding positions.
ENCODER STATUS:
Abs M1 Indicates whether there is a reading error or operating malfunction on the absolute encoder of motor 1.
OUTPUTS:
Out 1 Indicates when output 1 is active. Caution – 12/24 V DC voltage present.
Out M1 Indicates when motor 1 is in operation.
ALARMS:
Out 1 overload Indicates an electrical overload or short circuit on output 1 or on the courtesy light of the control unit.
Out 2 overload Indicates an electrical overload or shortcircuit at output 2.
M1 low overtravel Indicates that the absolute encoder of motor 1 is in a position close to the minimum limit (0%), below which the
motor does not function.
M1 high overtravel Indicates that the absolute encoder of motor 1 is in a position close to the maximum limit (100%), over which the
motor does not function.
other parameters
This function enables display of the operating status of some parameters measured by the control unit. These parameters are described in Table 5.
TABLE 5: DIAGNOSTICS of other parameters
PARAMETER DESCRIPTION
• Diagnostics 2
MISCELLANEOUS PARAMETERS:
Courtesy light Indicates the timer for shutoff of the courtesy light.
Pause time Indicates the timer for counting the pause time between one manoeuvre and the next.
Service voltage Indicates the voltage supplied to external devices.
Bus medium current Indicates the current absorption of the devices connected to the bluebus output, calculated as a percentage.
MOTOR 1:
Torque Indicates the torque generated by motor 1 during the manoeuvre, calculated as a percentage.
Speed Indicates the speed of motor 1 during the manoeuvre, calculated as a percentage.
Voltage Indicates the mean voltage to be supplied to motor 1 during the manoeuvre, calculated as a percentage.
Position Indicates the physical encoder position, as a percentage: the limits implemented are the encoder minimum limit
(equal to 0 = 0%) and the encoder maximum limit (equal to 4096 = 100%). This data is useful to understand whether
the encoder is in an overtravel position, i.e. outside the operating zone of the absolute encoder.
bluebus device diagnostics
This function displays the type, operating status and conguration of devices connected ot the Bluebus output. These parameters are described in Table 6.
TABLE 6: DIAGNOSTICS of bluebus devices
PARAMETER DESCRIPTION
• Bluebus
PHOTOCELLS
PHOTO Indicates whether the photocell is present, the relative operating status and the correct memorisation in the control
unit.
PHOTO II Indicates whether the photocell is present, the relative operating status and the correct memorisation in the control
unit.
PHOTO 1 Indicates whether the photocell is present, the relative operating status and the correct memorisation in the control
unit.
PHOTO 1 II Indicates whether the photocell is present, the relative operating status and the correct memorisation in the control
unit.
PHOTO 2 Indicates whether the photocell is present, the relative operating status and the correct memorisation in the control
unit.
PHOTO 2 II Indicates whether the photocell is present, the relative operating status and the correct memorisation in the control
unit.
PHOTO 3 Indicates whether the photocell is present, the relative operating status and the correct memorisation in the control
unit.
FT A Indicates whether the sensitive edge is present, the relative operating status and the correct memorisation in the
control unit.
FT B Indicates whether the sensitive edge is present, the relative operating status and the correct memorisation in the
control unit.
FT C Indicates whether the sensitive edge is present, the relative operating status and the correct memorisation in the
control unit.
OPEN PHOTO Indicates whether the control photocell is present, the relative operating status and the correct memorisation in the
control unit.
OPEN PHOTO II Indicates whether the control photocell is present, the relative operating status and the correct memorisation in the
control unit.
COMMANDS:
CMD 1 Indicates whether the control photocell is present, the relative operating status and the correct memorisation in the
control unit.
CMD 2 Indicates whether the control photocell is present, the relative operating status and the correct memorisation in the
control unit.
CMD 3 Indicates whether the control photocell is present, the relative operating status and the correct memorisation in the
control unit.
