FUNCTION
sca (= gate open indicator)
gate open
gate closed
maintenance indicator light
flashing light
courtesy light
electric lock 1
DESCRIPTION
The programmed light indicates the operating status of the
control unit.
light off = application stationary in maximum Closing position;
slow flashing = application Opening manoeuvre execution
phase;
quick flashing = application Closing manoeuvre execution
phase;
light permanently on = application stationary in position oth-
er than maximum closing
Output active 24 Vdc / max 4 W
The programmed light indicates the operating status of the
control unit.
light on = application in maximum Opening position;
light off = application in other positions.
Output active 24 Vdc / max 4 W
The programmed light indicates the operating status of the
control unit.
light on = application in maximum Closing position;
light off = application in other positions
Output active 24 Vdc / max 4 W
The programmed light indicates the count of manoeuvres
completed and therefore the need (or not) for system mainte-
nance operations.
light on for 2 sec at start of Opening manoeuvre = number
of manoeuvres less than 80%;
light flashing during execution of entire manoeuvre = num-
ber of manoeuvres between 80 and 100%;
light always flashing = number of manoeuvres over 100%.
Output active 24 Vdc / max 4 W
This function enables the flashing light to indicate execution of
a manoeuvre in progress with flashes at regular intervals (0.5
sec ON, 0.5 sec OFF).
Output active 12 Vdc / max 21 W
This function type is ON/OFF. Important – For safety reasons,
as the light is not controlled by a timer, use of an adequate light
is recommended able to withstand the heat of the light emitted.
Output active 24 Vdc / max 4 W
With this function programmed, when an Opening manoeuvre
is performed the electric lock is activated for a time as set in
the function “electric lock time – output configuration”.
Output active 12 Vac / max. 15 VA
In this output the user can select one of the functions specified in Table 3.
TABLE 3: OUTPUT CONFIGURATION
Output 2 (electric lock)
radio channel no.4 If this radio channel is set for the configuration of output 1
(flash), this channel is activated when a command is sent with
the transmitter. This mode is useful if installing external devices
(for example, an auxiliary light) in the same system to be con-
trolled with a single transmitter.
WARNING – If this channel is not free on the control unit re -
ceiver, as previously memorised with a command, the control
unit activates exclusively the programmed output when the
channel is activated with the transmitter, ignoring the com-
mand to the motor.
Output active 24 Vdc / max 4 W
