courtesy light
electric lock 1
suction cup 1
red traffic light
green traffic light
radio channel no.1
radio channel no.2
radio channel no.3
This function type is ON/OFF. Important – For safety reasons,
as the light is not controlled by a timer, use of an adequate
light is recommended able to withstand the heat of the light
emitted.
Output active 24 Vdc / max 4 W
With this function programmed, when an Opening manoeuvre
is performed the electric lock is activated for a time as set in
the function “electric lock time – output configuration”.
Output active 12 Vac / max 15 VA
With this function programmed, the suction cup is activated
when the application is in the maximum Closing position. Note
– The suction cup is disabled in all other situations.
Output active 24 Vdc / max 4 W
This function indicates activity of the application during the
phases of a Closing manoeuvre.
slow flashing = execution of Closing manoeuvre;
light permanently on = application in maximum Closing
position;
light off = application in other positions
Output active 24 Vdc / max 4 W
This function indicates activity of the application during the
phases of an Opening manoeuvre.
slow flashing = execution of Opening manoeuvre;
light permanently on = application in maximum Opening
position;
light off = application in other positions
Output active 24 Vdc / max 4 W
If this radio channel is set for the configuration of output 1
(flash), this channel is activated when a command is sent with
the transmitter. It is useful if installing external devices (for
example, an auxiliary light) in the same system to be controlled
with a single transmitter.
WARNING – If this channel is not free on the control unit re -
ceiver, as previously memorised with a command, the control
unit activates exclusively the programmed output when the
channel is activated with the transmitter, ignoring the com-
mand to the motor.
Output active 24 Vdc / max 4 W
If this radio channel is set for the configuration of output 1
(flash), this channel is activated when a command is sent with
the transmitter. This mode is useful if installing external devices
(for example, an auxiliary light) in the same system to be con-
trolled with a single transmitter.
WARNING – If this channel is not free on the control unit re -
ceiver, as previously memorised with a command, the control
unit activates exclusively the programmed output when the
channel is activated with the transmitter, ignoring the com-
mand to the motor.
Output active 24 Vdc / max 4 W
If this radio channel is set for the configuration of output 1
(flash), this channel is activated when a command is sent with
the transmitter. This mode is useful if installing external devices
(for example, an auxiliary light) in the same system to be con-
trolled with a single transmitter.
WARNING – If this channel is not free on the control unit re -
ceiver, as previously memorised with a command, the control
unit activates exclusively the programmed output when the
channel is activated with the transmitter, ignoring the com-
mand to the motor.
Output active 24 Vdc / max 4 W
