3.2) Fixing the control unit
Insertthetwoscrewsintheupperholesprovided,slidingthemontheguideasing.3aandpartlyscrewingthemin.Turnthecontrolunit
through 180° and perform the same operation with the other 2 screws. Fix the control unit on to the wall.
Fixthecoveronthedesiderdpart(withopeningontherightorleft),pressrmlyonthearrows.
To remove the cover, press with a screwdriver on the join and push upwards at the same time.
!

and the directions provided in this manual.
3) Installation
3.1) Preliminary checks
Before proceeding with the installation:
•Checkthatallthematerialsareinexcellentcondition,suitablefor
use and compliant with current standards.
•Ensurethatthestructureofthegateissuitableforautomation.
•Ensurethatthemountingpositionsofthevariousdevicesarepro-
tectedfromimpactandthatthemountingsurfacesaresufciently
sturdy.
•Installcable or pipe leads only atthebottom of the unit; for no
reason whatsoever must the side and top walls be perforated. The
cables must only enter the unit from the bottom!
•Insertsuitablemechanicalstops,anchoredtotheground,bothfor
opening and closing manoeuvres.
•Componentsmustneverbeimmersedinwaterorotherliquids.
 Keep away from heat sources and open ames; in acid, saline
or potentially explosive atmosphere; this could damage A60 and
cause malfunctions or hazardous situations.
•Ifthereisanaccessdoorintheleaf,orwithintherangeofmove-
ment of the gate, make sure that it does not obstruct normal travel.
Mount a suitable interlock system if necessary.
•Onlyconnectthecontrolunittoapowersupplylineequippedwith
a safety grounding system.
•Thepowersupplylinemustbeprotectedbysuitablemagnetother-
mal and differential switches.
• A disconnection device must be inserted in the power supply
linefromtheelectricalmains(thedistancebetweenthecontacts
must be at least 3.5mm with an overvoltage category of III) or
equivalent system, for example an outlet and relative plug. If the
disconnection device for the power supply is not mounted near the
automation, it must have a locking system to prevent unintentional,
unauthorised connection.
3a 3b 3c 3d
