TABLE 1-D: COMMAND CONFIGURATION
MODE DESCRIPTION
Close - stop - close Operating mode set in factory (Input 3 - “close” command). This executes the
above sequence.
Apartment block 1 close This executes the sequence “close - close”.
Apartment block 2 close This executes the sequence “close - close”. Important – When sending a
command, if the transmitter key is held down for more than 2 seconds, the
control unit activates a Stop.
Hold-to-run close The Closing manoeuvre is executed exclusively if the hold-to-run command
is used.
Stop
In this category, you can choose one of the operating modes listed in table 1-E.
TABLE 1-E: COMMAND CONFIGURATION
MODE DESCRIPTION
Stop Operating mode set in factory. When the control unit receives the command,
it stops the manoeuvre in progress gradually and in a short time (not instantly).
Stop and brief inversion When the control unit receives the “stop” command, it stops the manoeuvre
in progress and activates the application to perform a brief inversion in the
opposite direction.
In this category, you can choose one of the operating modes listed in table 1-F.
TABLE 1-F: COMMAND CONFIGURATION
MODE DESCRIPTION
Stop and inversion Operating mode set in factory. When the control unit receives the command,
it stops the Closing manoeuvre in progress and activates a total inversion
(Opening). Caution! – During execution of the Opening manoeuvre, this com-
mand is ignored.
Stop and brief inversion When the control unit receives the command, it stops the Closing manoeuvre
in progress and activates the application to perform a brief inversion in the
opposite direction (Opening). Caution! – During execution of the Opening ma-
noeuvre, this command is ignored.
Stop When the control unit receives the command is stop the current Close ma-
noeuvre. Caution! – During execution of the Opening manoeuvre, this com-
mand is ignored.
Photo 1
In this category, you can choose one of the modes listed in table 1-G.
TABLE 1-G: COMMAND CONFIGURATION
MODE DESCRIPTION
Stop When the control unit receives the command is stop the current Close ma-
noeuvre. Caution! – During execution of the Opening manoeuvre, this com-
mand is ignored.
Temporary stop When the control unit receives the command, it stops the Closing manoeuvre
for the entire time that the command remains active. Otherwise, when the
command is no longer active, the control unit activates the application to
perform an Opening manoeuvre. Caution! – During execution of the Opening
manoeuvre, this command is ignored.
Photo 2
In this category, you can choose one of the modes listed in table 1-H.
TABLE 1-H: COMMAND CONFIGURATION
MODE DESCRIPTION
Stop and inversion Operating mode set in factory. When the control unit receives the command,
it stops the Opening manoeuvre in progress and activates a total inversion
(Closing). Caution! – During execution of the Opening manoeuvre, this com-
mand is ignored.
Stop and brief inversion When the control unit receives the command, it stops the Opening manoeu-
vre in progress and activates the application to perform a brief inversion in
the opposite direction (Closing). Caution! – During execution of the Opening
manoeuvre, this command is ignored.
Stop When the control unit receives the command, it stops the Opening manoeu-
vre in progress. Caution! – During execution of the Opening manoeuvre, this
command is ignored.
Photo 3
In this category, you can choose one of the modes listed in table 1-I.
