COMMAND CONFIGURATION
This item covers the command categories associable with inputs 1 - 2 - 3 (refer to the section “input conguration - Table 1” to check the commands avail-
able). Each command category features various operating modes as described in a table (1-A, 1-B, etc.):
Step-by-step
In this command category the user can select one of the operating modes specied in Table 1-A.
TABLE 1-A: COMMAND CONFIGURATION
MODE DESCRIPTION
Industrial mode This runs the sequence “open in semiautomatic- close in hold-to-run”.
Open - stop - close - stop This executes the above sequence.
Open - Stop - Close - Open Operating mode set in factory (Input 1 - “step-by-step” command). This ex-
ecutes the above sequence.
Open - Close - Open - Close This executes the above sequence.
Apartment block 1 step-by-step Runs the sequence “close - stop - open - open”, until it reaches the fully open
position. Note – If another command is sent after this one, the application
executes the Closing manoeuvre with the same sequence.
Apartment block 2 step-by-step Runs the sequence “close - stop - open - open” until the fully open position
is reached. Note – If another command is sent after this one, the application
executes the Closing manoeuvre with the same sequence.
Important – When sending a command, if the transmitter key is held down for
more than 2 seconds, the control unit activates a Stop.
Step-by-step 2 This executes the sequence “open - stop - close - open”. Important – When
sending a command, if the transmitter key is held down for more than 2 sec-
onds, the control unit activates a “partial open 1” command (input congura-
tion > Table 1).
Hold-to-run The Opening or Closing manoeuvre is executed exclusively if the transmitter
key is held down (hold-to-run).
Partial open
In this command category the user can select one of the operating modes specied in Table 1-B.
TABLE 1-B: COMMAND CONFIGURATION
MODE DESCRIPTION
Open - stop - close - stop Operating mode set in factory. This executes the above sequence.
Open - Stop - Close - Open This executes the above sequence.
Open - Close - Open - Close This executes the above sequence.
Apartment block 1 step-by-step This executes the sequence “close - stop - partial open 1- partial open 1”
until the position is reached as programmed in the function “Partial Open 1”.
Note – If another command is sent after this one, the application executes the
Closing manoeuvre with the same sequence.
Apartment block 2 step-by-step This executes the sequence “close - stop - partial open 1 - partial open 1”
until the position is reached as programmed in the function “Partial Open 1”.
Note – If another command is sent after this one, the application executes
the Closing manoeuvre with the same sequence. Important – When sending
a command, if the transmitter key is held down for more than 2 seconds, the
control unit activates a Stop.
Hold-to-run The Partial open 1 or Closing manoeuvre is executed exclusively if the trans-
mitter key is held down (hold-to-run).
Industrial mode This runs the sequence “open in semiautomatic- close in hold-to-run”.
Open
In this command category the user can select one of the operating modes specied in Table 1-C.
TABLE 1-C: COMMAND CONFIGURATION
MODE DESCRIPTION
Open - Stop - Open Operating mode set in factory (Input 2 - “open” command). This executes the
above sequence.
Apartment block 1 This executes the sequence “open - open”. Important – When sending a com-
mand, if the transmitter key is held down for more than 2 seconds, the control
unit activates a Stop.
Apartment block 2 This executes the Opening sequence.
Open 2 Important – When sending a command, if the transmitter key is held down for
more than 2 seconds, the control unit activates a “partial open 1” command
(input conguration > Table 1).
Hold-to-run Open The Opening manoeuvre is executed exclusively if the transmitter key is held
down (hold-to-run).
Close
In this command category the user can select one of the operating modes specied in Table 1-D.
