Nice RB600 - Foundation and Cable Preparation

English – 5
D C BF AFE D
a
b
b
f
e
c
c
d
2
Before installing the system, check the gearmotor’s overall dimensions (Fig. 3) and installation measurements (Fig. 4):
3
330 mm
303 mm
92 mm
212 mm
HS: 98 mm
4
0 – 10 mm
0 – 50 mm
192 mm
330 mm
0 – 10 mm
0 – 50 mm
192 mm
330 mm
01. Dig the foundation and arrange the tubes for the electrical
cables
