Nice RO500 User Manual

1
2
3
4
5
6
290 mm 195 mm
68 mm
250 mm
90 mm
D3
D2 D2
D6
D7 D7
D1
D4
D5 D5

Nice RO500 Specifications

General

Mains power supply	230 Vac 50 Hz
Max. power absorption	400 W
Line Absorption	1.7 A
Max. Service current 24 V	150 mA (voltage can vary by ± 25%)
Motor	Asynchronous-single phase
Limit switch type	Electromechanical
Built-in capacitor	12 nF
Input impedance	52 ohm
Protection rating	IP 44
Thermal protection	140 °C
Operating temperature	From -20 °C to +50 °C, from -20 to +55° C
Maximum torque (corresponding to force)	15 Nm (500 N)
Nominal torque (corresponding to force)	8 Nm (270 N)
Nominal speed	0.18 m/s
Max. No. Cycles per hour	9 (leaf 7 metres)
Max. No. consecutive Cycles	5
Work time	Adjustable from 2.5 to > 40 s., or from < 40 to > 80 s. with TLM
Pause time	Adjustable from 5 to > 80 s.
Sensitivity	Better than 0.5 V
Flashing light output	For connection of flashing light to power mains (Max. power 40 W)
Decoding	“O-Code” / “FloR” / “TTS”; or Flo”; or “Smilo”
Reception frequency	433.92 MHz

Weight and Dimensions

Maximum leaf weight	500 Kg
Maximum leaf length	7 m
Dimensions	290 x 195 x h 250 mm
Weight	8 Kg
