Nice ROBO Instructions And Warnings For The Fitter

4
control unit
gearmotors
robo, thor, otto
Warnings:
This manual has been especially written for use by
qualified fitters. No information given in this manual can be
considered as being of interest to end users!
This manual only refers to this control unit and may not be
used for different products.
Do not install the unit before you have read all the instructions at least
once.
!
Table of contents: page
1 Description of the product 5
2 Installation 6
2.1 Typical system layout 6
2.2 Electrical connections 6
2.2.1 Electrical diagram 7
2.2.2 Description of connections 7
2.2.3 Phototest 8
2.2.4 Checking connections 9
3 Adjustments 9
4 Testing 10
5 Operating modes 11
page
6 Programmable functions 11
6.1 Description of functions 12
7 Using 2 control units on opposed leafs 13
8 Accessories 14
9 Maintenance 14
10 Disposal 14
11 What to do if... 15
12 Technical specifications 15

Nice ROBO Specifications

General

Max Gate Weight	600 kg
Max Gate Length	12 m
Maximum Gate Weight	600 kg
Maximum Gate Width	12 m
Opening Speed	12 m/min
Closing Speed	12 m/min
Safety Features	Obstacle detection, Photocell input
Control Type	Remote control, Keypad
Battery Backup	Yes (optional)
Power Supply	230V AC, 50Hz
Operating Temperature	-20°C to +55°C
Protection Level	IP44
Motor Voltage	24V DC
Motor Type	DC, Brushless
