WARNINGS: •Alltechnicalspecicationsstatedinthissectionrefertoanambienttemperatureof20°C(±5°C).•NiceS.p.a.reservestheright
toapplymodicationstoproductsatanytimewhendeemednecessary,whilemaintainingthesameintendeduseandfunctionality.
MODEL TOO4500 TOO4524 TOO3000 TOO3024
Motor voltage [V] 230 24 230 24
Frequency [Hz] 50 DC 50 DC
Max gate length [m] 4.5 4.5 3 3
Max gate weight (kg) 250 250 300 300
IP protection rating 54 54 54 54
Operating temperature [C°] -20 to +50 -20 to +50 -20 to +50 -20 to +50
Weight of motor [kg] 6 5.5 6 5.5
Speed [m/s] 0.016 0.014 0.016 0.014
Travel [mm] 500 500 400 400
Capacitor [mF] 7 - 7 -
Nominal current draw [A] 1.1 1.1 1.1 1.1
Maximum current draw [A] 1.5 5 1.5 5
Nominal power draw [W] 250 30 250 30
Maximum power draw [W] 340 120 340 120
Nominal force [N] 300 300 300 300
Maximum force [N] 2000 1800 2000 1800
Cycles (cycles/hour) 24 continuous 24 continuous
Control unit A60 MC424L A60 MC424L
Dimensions [mm] 800x100x177h 800x100x177h 800x100x177h 800x100x177h
9
TECHNICAL SPECIFICATIONS
CE Declaration of Conformity and declaration of incorporation of partly completed machinery
Declaration in accordance with the following Directives: 12004/108/EC (EMC); 2006/42/EC (MD) annex II, part B
Note – The content of this declaration corresponds to that specified in the official document deposited at the Nice S.p.A. headquarters
and,inparticular,tothelatestrevisededitionavailablepriortothepublishingofthismanual.Thetexthereinhasbeenre-editedforedito-
rial purposes. A copy of the original declaration can be requested from Nice S.p.A. (prov. of Treviso) Italy.
Declaration number: 507/TOO Revision: 0 Language: EN
Manufacturer's Name: NICE s.p.a.
Address: Via Pezza Alta N°13, 31046 Rustignè di Oderzo (TV) Italy
Person authorized to compile the technical documentation: NICE s.p.a.
Type of product: Telescopic motor for swing gates
Model / Type: TOO3000, TOO3024, TOO4500, TOO4524
Accessories:
TheundersignedMauroSordini,asChiefExecutiveOfficer,herebydeclaresunderhisownresponsibilitythattheproductsidentifiedabove
comply with the provisions of the following directives:
•DIRECTIVE2004/108/ECOFTHEEUROPEANPARLIAMENTANDOFTHECOUNCILof15December2004ontheapproximationof
the laws of the Member States relating to electromagnetic compatibility and repealing Directive 89/336/EEC, in accordance with follow-
ing harmonised standards: EN 61000-6-2:2005, EN 61000-6-4:2007
In addition, the product conforms to the following directive in accordance with the provisions applicable to partly completed machinery:
• Directive 2006/42/EC of the European Parliament and of the Council of 17 May 2006 on machinery, and amending Directive 95/16/EC
(recast), in accordance with the following harmonised standards:
•IherebydeclarethatthepertinenttechnicaldocumentationhasbeendraftedinaccordancewithAnnexVIIBofDirective2006/42/EC
and that the following essential requirements have been satisfied: 1.1.1- 1.1.2- 1.1.3- 1.2.1-1.2.6- 1.5.1-1.5.2- 1.5.5- 1.5.6- 1.5.7-
1.5.8- 1.5.10- 1.5.11
• The manufacturer agrees to submit pertinent information on the partly completed machinery to the national authorities, in response to a
motivated request, without affecting its intellectual property rights.
• If the partly completed machinery is operated in a European country with an official language other than the language used in this dec-
laration, the importer must include a translation with this declaration.
• The partly completed machinery must not be operated until the final machine in which it is to be incorporated is declared to conform to
the provisions of Directive 2006/42/EC, if applicable.
Theproductalsocomplieswiththefollowingstandards:EN60335-1:2012;EN60335-2-103:2003+A1:2009
The parts of the product which are subject to the following standards comply with them:
EN 13241-1:2003, EN 12445:2002, EN 12453:2002, EN 12978:2003
Oderzo, 9 May 2014 Mr. Mauro Sordini
(ChiefExecutiveOfficer)
EN
English – 4
