Nice UST1K

14 – English
EN
Coupling terminal
control devices
Radio coupling
Limit switch coupling
terminal
PE screw terminal
OPENING setting
button
J1 U-bolt
LED 2
CLOSING setting
button
Key switch connection
Triple button connection
Brake relay
connection
Antenna screw
terminal
Coupling terminal
of photoelectric barrier passage
Plug connection
for cover LED
T2 setting button
DIP switch
Display
Coupling terminal red trac
lights contacts with zero
potential limit switch
S2 rotary selector
Button T1 manual
transmitter setting
Network coupling terminal
J1 U-bolt
Motor coupling terminal
Coupling terminal of
contact barrier +
door half height
Wiring diagram UST1K - starting from 2.2kW
