ES
Español– 15
Esquema electrónico UST1K-1,1kW
Borne
acoplable
Pulsador paso a paso
Acoplamiento radio
Borne acoplable
interruptor de tope
Borne acoplable elementos
de seguridad contactos
de potencial cero
Borne de tornillo PE
Tecla de ajuste
APERTURA
Tecla de ajuste
CIERRE
Acoplamiento
para interruptor
de llave
Acoplamiento tecla triple
Acoplamiento para
relé freno
Borne de tornillo
Borne acoplable
barrera fotocélula
Conexión a enchufe
para LED asistencia
Tecla ajuste T2
Interruptor
DIP
Display
Semáforo rojo
Tecla T1 ajuste
del transmisor
Borne alimentación
Borne acoplable
motor
Borne acoplable barra
de contacto + mitad
altura puerta
Selettore rotante S2
Cavallotto J2
