Nico Technology 7600RF - Product Information; Key Functional Elements

7600RF RF Receiver [Preliminary] User’s Manual
2 Product Information
2.1 Functional Elements
Figure 1.1 7600RF RF Receiver
No Description
1 Service Pin button and service pin LED indicator
2 Reset button and reset LED indicator
3 LonWorks network interface
4 Power supply. 12~24VDC
5 DIP switch for wireless channel ID setting
2.2 Variants and Identifications
2.3 Scope of Delivery
3 Installation
This chapter first describes the installation of the device; the installation of the
configuration software is described in section 2.4.
