AMC Roll Over Limit (31.010) = 0 > 0
VM_AMC_POSITION_UNIPOLAR[MAX] 2147483647 / AMCAutoResolutionScaling(31.016) AMCRollOverLimit (31.010) - 1
VM_AMC_POSITION_UNIPOLAR[MIN] 0 0
Identifier VM_AMC_RATE
Description Range applied to the parameters showing the AMC acceleration
Units User units / ms / ms
Range of [MIN] 1073742.824
Range of [MAX] 1073741.823
VM_AMC_RATE_UNIPOLAR[MAX] = 1073741.823 / AMCAutoResolutionScaling(31.016)
VM_AMC_RATE_UNIPOLAR[MIN] = 1073741.824 / AMCAutoResolutionScaling(31.016)
Identifier VM_AMC_RATE_UNIPOLAR
Description Unipolar version of VM_AMC_RATE
Units User units / ms / ms
Range of [MIN] 0
Range of [MAX] 1073741.823
VM_AMC_RATE_UNIPOLAR[MAX] = 1073741.823 / AMCAutoResolutionScaling(31.016)
VM_AMC_RATE_UNIPOLAR[MIN] = 0
Identifier VM_AMC_ROLLOVER
Description Maximum applied to the AMC Rollover parameter
Units User units
Range of [MIN] 0
Range of [MAX] 1073741823
VM_AMC_ROLLOVER[MAX] = 1073741823 / AMCAutoResolutionScaling(31.016)
VM_AMC_ROLLOVER[MIN] = 0
Identifier VM_AMC_SPEED
Description Range applied to the parameters showing the AMC speed
Units User units / ms
Range of [MIN] -21474836.48
Range of [MAX] 21474836.47
VM_AMC_SPEED[MAX] = 21474836.47 / AMCAutoResolutionScaling(31.016)
VM_AMC_SPEED[MIN] = -21474836.48 / AMCAutoResolutionScaling(31.016)
Identifier VM_AMC_SPEED_UNIPOLAR
Description Unipolar version of VM_AMC_SPEED
Units User units / ms
Range of [MIN] 0
Range of [MAX] 21474836.47
VM_SPEED_UNIPOLAR[MAX] = 21474836.47 / AMCAutoResolutionScaling(31.016)
VM_SPEED_UNIPOLAR[MIN] = 0
Identifier VM_DC_VOLTAGE
Description Range applied to d.c. voltage reference parameters
Units V
Range of [MIN] 0
Range of [MAX] 0 to 1190
VM_DC_VOLTAGE[MAX] is the full scale d.c. link voltage feedback (over voltage trip level) for the drive. This level is drive voltage rating dependent.
See the table below.
Voltage level 200V 400V 575V 690V
VM_DC_VOLTAGE[MAX] 415 830 990 1190
VM_DC_VOLTAGE[MIN] = 0
